TITAN – Electronic Tankless Water Heater 16 kW – 240 V / 66 A

Dimensions:

• Width: 7 in
• Height: 12 in
• Depth: 3 in

Electrical Specifications:

• Voltage: 240 V (also supports 208 V)
• Current Draw: 66 A @ 240 V (55 A @ 208 V)
• Power Output: 16 kW
• Minimum Flow Rate to Activate: 0.4 GPM
• Shut-off Flow Rate: 0.3 GPM
• Maximum Flow Rate: 4.0 GPM
• Recommended Breaker: 70 A double pole with #6 AWG wire

Performance (Temperature Rise @ Flow Rate):

• 1.0 GPM → +109 °F
• 1.5 GPM → +73 °F
• 2.0 GPM → +55 °F
• 2.5 GPM → +44 °F
• 3.0 GPM → +36 °F
• 4.0 GPM → +27 °F

Key Features:

• Advanced Quad-4 electronic proportional control
• Digital display for temperature, voltage, and amperage
• Dual Nichrome heating elements inside copper and brass chambers
• Energy efficiency up to 99.5 %
• Activates at low flow (0.4 GPM)
• Wall-mountable compact steel casing
• Complies with UL-499, ETL/Met Labs, and NSF-372 standards

Warranty:

• 1-year warranty on components
